ESP32-C6 1.43inch AMOLED Round Touch Display Development Board, 160MHz RISC-V Processor,WiFi 6/Bluetooth 5/IEEE 802.15.4, 466×466 Pixels, Dual Digital Microphone Array, Support AI Speech Interaction
5.0 (38 items)
Limited Time SaleUS$21.88 cheaper than the new price!!
Free cash-on-delivery fees for purchases over $99
Product details
| Management number | 220078400 | Release Date | 2026/05/03 | List Price | US$14.59 | Model Number | 220078400 | ||
|---|---|---|---|---|---|---|---|---|---|
| Category | |||||||||
- Powerful ESP32-C6 MCU & Multimode Wireless Communication: ESP32-C6 high-performance 32-bit RISC-V processor(160 MHz), + Wi-Fi 6/Bluetooth 5/Zigbee 3.0 multi-mode communication, with superior RF performance. Built-in 512KB HP SRAM, 16KB LP SRAM, 320KB ROM and 16MB Flash memory.
- Rich Integrated Functions: Onboard 1.43inch AMOLED capacitive touch display (466×466 resolution, 16.7M colors, CO5300 driver chip (QSPI Interface) + FT6146 capacitive touch (I2C Interface)), highly integrated PCF85063 RTC chip, 6-axis IMU, TF card slot, low power audio encoding and decoding chips, dual MIC circuit, Lithium battery header, and so on. Reserved USB, UART, I2C, and GPIO interfaces for flexible expansion, to meet diverse product development needs.
- AI Voice Interaction and Motion Sensing: Dual digital microphone array (Supports accurate voice recognition and near-field/far-field voice wake-up),Onboard audio encoding and decoding chips (Audio Input and Output). Supports AI Speech Interaction. Allows access to online large model platforms such as DeepSeek, Doubao,ChatGPT, etc. QMI8658 6-axis IMU --3-axis accelerometer and 3-axis gyroscope (for detecting motion gesture, counting steps, etc.)
- Flexible Expansion & Custom Development: Provides USB, UART, I2C, GPIO and dedicated SH1.0 4PIN / 2x 2.54mm 4PIN interfaces, easily connect various sensors, modules and peripherals to meet diverse development needs. PWR and BOOT programmable buttons for easy custom function development. TF Card Slot for extended storage and fast data transfer, for applications such as data recording and media playback.
- Comes with Online Development Resources and Tutorials to help you get started quickly: bit.ly/3IKPnjA
| Brand | UeeKKoo |
|---|---|
| Manufacturer | UeeKKoo |
| Model Number | ESP32-C6-Touch-AMOLED-1.43 |
| BuiltIn Media | 1217 8Ω 2W cavity speaker ×1, ESP32-C6-Touch-AMOLED-1.43 x1, SH1.0 4PIN cable ~100mm ×2 |
| Warranty Description | Technical Support is provided |
